# Adjacency list representation of undirected graph in kotlin

Kotlin program for Adjacency list representation of undirected graph. Here problem description and explanation.

```
/*
Kotlin Program for
Undirected graph representation by using adjacency list
*/
class AjlistNode
{
// Vertices node key
var id: Int;
var next: AjlistNode ? ;
constructor(id: Int)
{
// Set value of node key
this.id = id;
this.next = null;
}
}
class Vertices
{
var data: Int;
var next: AjlistNode ? ;
var last: AjlistNode ? ;
constructor(data: Int)
{
this.data = data;
this.next = null;
this.last = null;
}
}
class Graph
{
// Number of Vertices
var size: Int;
var node: Array < Vertices ? > ;
constructor(size: Int)
{
// Set value
this.size = size;
this.node = Array(size)
{
null
};
this.setData();
}
// Set initial node value
fun setData(): Unit
{
if (this.size <= 0)
{
println("\nEmpty Graph");
}
else
{
var index: Int = 0;
while (index < this.size)
{
this.node[index] = Vertices(index);
index += 1;
}
}
}
// Connect two nodes
fun connect(start: Int, last: Int): Unit
{
val edge: AjlistNode = AjlistNode(last);
if (this.node[start]?.next == null)
{
this.node[start]?.next = edge;
}
else
{
// Add edge at the end
this.node[start]?.last?.next = edge;
}
// Get last edge
this.node[start]?.last = edge;
}
// Handling the request of adding new edge
fun addEdge(start: Int, last: Int): Unit
{
if (start >= 0 && start < this.size &&
last >= 0 && last < this.size)
{
this.connect(start, last);
if (start == last)
{
// When self loop
return;
}
this.connect(last, start);
}
else
{
// When invalid nodes
println("\nHere Something Wrong");
}
}
fun printGraph(): Unit
{
if (this.size > 0)
{
var index: Int = 0;
// Print graph ajlist Node value
while (index < this.size)
{
print("\nAdjacency list of vertex " + index + " :");
var temp: AjlistNode ? = this.node[index]?.next;
while (temp != null)
{
// Display graph node
print(" " + this.node[temp.id]!!.data);
// Visit to next edge
temp = temp.next;
}
index += 1;
}
}
}
}
fun main(args: Array < String > ): Unit
{
// 5 implies the number of nodes in graph
val g: Graph = Graph(5);
// Connect node with an edge
g.addEdge(0, 1);
g.addEdge(0, 2);
g.addEdge(0, 4);
g.addEdge(1, 2);
g.addEdge(1, 4);
g.addEdge(2, 3);
g.addEdge(3, 4);
// print graph element
g.printGraph();
}
```

**Output**

```
Adjacency list of vertex 0 : 1 2 4
Adjacency list of vertex 1 : 0 2 4
Adjacency list of vertex 2 : 0 1 3
Adjacency list of vertex 3 : 2 4
Adjacency list of vertex 4 : 0 1 3
```
